| The glory that is Saturn. The Cassini spacecraft was crossing the plane of the rings as it captured this image, so they are visible only as a sharp thin line running across the center of the image. The Sun is behind and below the viewer; hence the rings cast shadows on the planet's northern hemisphere clouds. Image credit: NASA. |
One can hardly blame Arthur C. Clarke for stubbornly insisting that the spaceship
Discovery travel to Saturn. Even with the minimal knowledge of the Saturn system we possessed in the year 1968, when the film
2001: A Space Odyssey had its debut and the novel by the same name first saw print, it was clear that the Saturn system is home to some intriguing space oddities which Clarke could put to good use in his narrative.
There are, of course, the rings. They make Saturn an austere work of art wrought in ice and orbital mechanics. Clarke attributed their creation to the same advanced aliens who uplifted humankind at the beginning of the book and film
2001, three or four million years before
Discovery's launch.
There is also peculiar Iapetus — which Clarke called Japetus (the German spelling) — a 1500-kilometer-diameter moon that is very dark on one side (its leading hemisphere as it orbits Saturn) and very bright on the other. The dark leading and bright trailing hemispheres mean that Iapetus, Saturn's second-largest moon after Titan, is very bright to Earth-based observers when its 79-day orbit puts it on one side of Saturn and very faint roughly 40 days later, when it moves into view on the other side of the planet.
Stanley Kubrick, who directed the film
2001, co-authored its screenplay, and received co-author credit on the novel, also sought to send
Discovery to Saturn, but had to settle for Jupiter. The film's overtaxed art department rebelled — Kubrick, ever the perfectionist, was given to demanding quick-turnaround changes which he subsequently threw away. Perhaps more important, a portrayal of Saturn convincing to 1968 film audiences proved too great a challenge for
2001's pioneering special-effects technology and skilled artisans. Had they known how improbable Saturn actually appears up close, Kubrick and the production crew might have cut themselves a bit of slack.
 |
| A raging storm in Saturn's northern hemisphere imaged by the Saturn-orbiting Cassini automated explorer 10 years after 2001. In 1968, observers using Earth-based telescopes believed Saturn's atmosphere to be practically featureless. Image credit: NASA. |
This is the third and last of a series of posts I have written this summer on real-world proposals for spacecraft and supporting infrastructure meant to emulate the spacecraft and infrastructure portrayed in the film and novel
2001. In the first installment, I described
2001's Earth-to-Moon transport system and a 1997 NASA Lewis Research Center (now called NASA Glenn Research Center) plan to partially replicate it using the International Space Station, nuclear-thermal rockets, and oxygen mined from the Moon.
In the second installment, I described two versions of
Discovery, the "hero ship" of
2001. I emphasized the film version of
Discovery; that is, the open-cycle gas-core nuclear-fission design the film's technical consultant, Frederick Ordway, described in the British Interplanetary Society magazine
Spaceflight in 1970.
This post picks up the
2001 story where my first post left off; then I will conclude the series by discussing a paper NASA Glenn researchers Craig Williams, Leonard Dudzinski, Stanley Borowski, and Albert Juhasz first presented in July 2001 and subsequently published as a NASA Technical Memorandum (TM) in March 2005. They describe a fusion-powered spacecraft meant to emulate
2001's
Discovery spacecraft which they name
Discovery II.
My first post ended with United States Astronautics Agency (USAA) bureaucrat-astronauts accidentally triggering an ancient alarm system. Radio waves blast from an alien black monolith in the Moon's great ray crater Tycho. The film
2001 then skips ahead 18 months, and we get our first look at
Discovery, her crew, and their daily routine.
As always, Clarke fills in missing details. The novel describes a host of robotic monitors scattered across the Solar System. Each in turn detects the radio signal from the Tycho monolith. Later we learn that data from the monitors enabled scientists on Earth to determine that the signal was directed at Saturn. In the movie, of course, the signal was beamed at Jupiter.
Fateful decisions are made at the highest level of the United States government. The ancient Tycho monolith and the signal aimed at Saturn are to be kept secret, ostensibly to prevent cultural shock and mass hysteria.
Preparations for Project Jupiter, the first piloted round-trip journey to the Solar System's largest planet, are by this time well advanced; this provides an opportunity. In search of those who received the Tycho monolith's signal,
Discovery's Jupiter mission is changed into a one-way Saturn mission with a gravity-assist flyby at Jupiter to gain speed. (I describe the early development of gravity-assist spaceflight in my "The Challenge of the Planets" post series: please see the "More Information" links at the bottom of this post.)
Discovery's crew of six is split up. A separately trained three-man "survey crew" travels to Saturn in hibernation; they thus remain safely incommunicado, ensuring that the mission's true purpose does not slip out during radio communications with Earth. Mission Commander David Bowman and his deputy, Frank Poole, remain awake. The pair form a minimal caretaker crew during the interplanetary phase of the Saturn mission.
Bowman and Poole are told that their mission aims to expand knowledge of the Solar System and to extend space technology capabilities, and that the survey crew has been placed aboard
Discovery in hibernation to conserve life support resources. Extending the limits of hibernation is, they are told, a major goal of their mission; after 100 days of scientific exploration at Saturn, the entire human crew is scheduled to hibernate for more than five years. Eventually, the as-yet-unbuilt spacecraft
Discovery II will arrive to take them home.
The NASA Glenn
Discovery II has no connection with the
Discovery II crew-retrieval spacecraft of the novel
2001. Clarke barely describes the latter. I encourage readers to speculate on the shape and capabilities of the
Discovery II in the
2001 universe.
The sixth member of the
Discovery crew, the HAL 9000 computer, is an artificial intelligence (AI). HAL 9000 knows the true purpose of the trip to Saturn; it is, however, programmed not to tell Bowman and Poole. The secrecy order creates a terrible conundrum for HAL 9000. Deep in its programming is a directive never to distort information, yet it has been commanded to do just that. Though an advanced AI, HAL 9000 is an innocent being, unable to tamp down what amounts to its conscience. The conflicting directives drive HAL 9000 to neurotic behavior which exacerbates its internal conflict, leading to psychosis and murder between Jupiter and Saturn.
Following the deaths of Poole and the three hibernating crewmen, Bowman is left alone aboard
Discovery with HAL 9000. For his own safety, he disconnects the AI. When he finishes, he is the only conscious being within a billion kilometers.
Mission Control belatedly tells Bowman the true purpose of
Discovery's mission. He begins a program of study to prepare himself for whatever he will encounter at Saturn. Without HAL 9000 to monitor him in hibernation, his has become a true one-way mission. Increasingly intrigued (and not a little daunted) by the prospect of contact with highly advanced aliens, Bowman is, however, able to put aside thoughts of a lonely death far from home. He even sympathizes with HAL 9000's plight.
 |
| The real thing: cylindrical projection of Iapetus image mosaic. The Cassini spacecraft captured images of Iapetus during flybys at different distances and under different lighting conditions; hence some are blurred and others are sharp. The leading hemisphere is at right. Image credit: NASA. |
Bowman uses
Discovery's telescopes to observe the Saturn system. He determines that Iapetus is his goal; the sharp line between the dark and light hemispheres is obviously artificial. Guided by Earth-based computer control,
Discovery of the book successfully fires her plasma jet propulsion system to place herself first into orbit about Saturn and then, with her last drops of hydrogen propellant, into orbit about Iapetus. Bowman then descends in a one-man space pod with the aim of landing atop a giant ("at least a mile high") black monolith standing at the exact center of the white hemisphere of Iapetus. Bowman calls it the Tycho monolith's "big brother."
The big monolith has plans for Bowman; it is, among other things, a Stargate, a shortcut through space-time leading into a galactic transit system. The lone survivor of
Discovery's crew is soon whisked across the Milky Way Galaxy to meet an enigmatic fate. I do not feel qualified to describe the intricacies of Stargate technology, so here I will conclude my overview of the second half of the novel
2001.
 |
| Discovery II: this forward view highlights the artificial-gravity section and the spacecraft's lone docking port. Image credit: NASA. |
Neither did I feel qualified to describe nuclear fusion rocket technology when I started work on this post, but I think after much study I have managed to accurately describe the NASA Glenn nuclear-fusion spacecraft
Discovery II. If, however, you detect what you believe is an error, it probably is, so please let me know so that I can correct it.
In their documents, the NASA Glenn team describes Jupiter and Saturn versions of its
Discovery II. As shown by their estimated weights, only minor differences distinguish the two versions; at 1690-metric-tons, the Jupiter-bound
Discovery II would weigh only nine metric tons less than the Saturn-bound version. In keeping with my already-established emphasis on Saturn in this post, I will focus on the Saturn version of NASA Glenn's
Discovery II.
The spacecraft's fusion rocket could in theory propel it to Saturn in 212 days when the planet was at opposition — that is, when Saturn was as close to Earth as it could be. The NASA Glenn team found that, all else being equal, a Saturn voyage at conjunction — that is, when Saturn was on the far side of the Sun and thus as distant from Earth as it could be — would last only 15% longer.
Discovery II's course to Saturn in both instances would follow nearly a straight line, not the graceful heliocentric curve of a minimum-energy Hohmann transfer.
At present, nuclear fusion occurs mainly inside stars. Human effort toward harnessing star power since the 1940s has emphasized fusion bombs. The U.S. exploded the first such weapon in 1952; a nuclear-fission bomb served as the "spark plug" for triggering the fusion explosion.
Development of electricity-generating fusion reactors, by contrast, has turned out to be more difficult than once assumed. The international ITER project, based in southern France, now hopes to test a prototype commercial fusion reactor in the 2030s.
Earth-based fusion electricity-generation technology would need to advance and considerable additional investigation into almost all engineering aspects of fusion rocketry would be necessary before a fusion rocket engine could become part of NASA's spaceflight tool kit. Nevertheless, the NASA Glenn engineers optimistically predicted that
Discovery II's maiden voyage might take place 30 years after they completed their NASA TM — that is, in the year 2035.
 |
| Discovery II: this aft view highlights the spacecraft's spheromak fusion reactor, four slush hydrogen tanks, and magnetic rocket nozzle. Image credit: NASA. |
Discovery II's fusion reactor would be of a modified Tokamak design. The original Tokamak, a 1970s Russian invention, was a normal torus — the proverbial doughnut — with a high-temperature plasma filling.
Discovery II's compact "spheromak" reactor would instead be shaped like a cored apple. Because it would be smaller, it would need less structure and fewer heavy components, such as electromagnets. The spheromak could thus be made much lighter than an equivalent Tokamak.
Though the NASA Glenn team took pains to make her fusion reactor as light as possible, at an estimated 310 metric tons it was still the most massive single hardware element of
Discovery II. The reactor weight estimate did not include support systems such as the fission reactor and battery bank that would supply the electrical power needed for fusion reactor startup.
 |
| Tokamak vs. spheromak. Image credit: Culham Centre for Fusion Energy. |
The NASA Glenn researchers opted for a deuterium/helium-3 (D/He-3) reactor fuel mix, partly because it is relatively well understood and partly because deuterium and helium-3 are relatively plentiful in the outer Solar System. The spacecraft would arrive at Saturn with an empty reactor fuel tank and refuel with deuterium and helium-3 mined from its icy moons and tawny cloud bands.
Discovery II's reactor would "burn" 11 metric tons of D/He-3 fuel to travel one-way to Saturn.
Nuclear fusion brings together atomic nuclei at high temperatures and pressures. Lightweight nuclei, such as those of various isotopes of helium and hydrogen, yield the most energy per unit, so are generally favored as reactor fuel. When atomic nuclei fuse, they release prodigious energy and create heavier elements. The heavier elements would, over time, build up in
Discovery II's fusion plasma, gradually reducing the reactor's performance. In addition, some small portion of the spheromak interior walls would erode away and mix with the swirling plasma.
The NASA Glenn team envisioned that heavy element and wall debris plasma (informally known as "ash") would form a "halo" against the outer wall of the plasma torus through skillful management of interlaced "toroidal" and "poloidal" magnetic fields, then a gutter-like magnetic "divertor" would vent the ash plasma from the aft end of the torus. The vented ash plasma would generate thrust.
The NASA Glenn team proposed to increase thrust by augmenting the ash plasma with hydrogen. Contact with ash plasma and passage through a constricted "throat" would heat the hydrogen until it also became plasma. A skeletal "magnetic nozzle" would then expel the plasma mix into space. The divertor and magnetic nozzle would together have a mass of only six metric tons, the team estimated.
Discovery II would include four cylindrical 37-meter-long propellant tanks containing a total of 861 metric tons of "slush" hydrogen. Chilling the hydrogen until it became slush using an on-board refrigeration system would increase its density, reducing the size and number of hydrogen tanks required.
To place its
Discovery II fusion rocket ship into space, the NASA Glenn team postulated the existence of a Heavy Lift Launch Vehicle (HLLV) capable of boosting 250 metric tons into a circular assembly orbit between 140 and 260 nautical miles above Earth. They argued that 250 tons would be very near the practical maximum payload for an HLLV. Placing
Discovery II components into assembly orbit would require that seven of the monster rockets launch in rapid succession, creating challenges in the areas of HLLV assembly and launch operations.
The
Discovery spacecraft of the book and film
2001 included large-diameter propulsion and crew modules. The latter was a sphere a little over 12 meters in diameter and the former was even longer and wider. The NASA Glenn team looked upon these with skepticism; such modules would likely be too large to launch intact, so would need to be at least partly built in space by spacewalking astronauts or through complex teleoperations.
They ignored the versatile piloted space pods portrayed in the book and film
2001, which might have made assembly easier, opting instead for pre-assembled launch packages that would fit within a 10-meter-diameter, 37-meter-long streamlined HLLV payload fairing. The self-propelled launch packages would, they explained, rendezvous and dock automatically in assembly orbit.
 |
| EASE truss assembly experiment, 1985. Image credit: NASA. |
Having said that, they then contradicted themselves by describing a series of HLLV payloads that would in fact require extensive in-space assembly. The first would include
Discovery II's 203-meter-long, six-metric-ton central truss. The NASA Glenn team explained that it would be based on the Experimental Assembly of Structures in EVA (EASE) Space Station truss concept tested during STS-61B spacewalks in late 1985.
The
Discovery II truss, hexagonal in cross section, would comprise 58 "bays," each built from 97 separate struts, nodes, and other parts. EASE assembly took place in the payload bay of the Space Shuttle
Atlantis.
Discovery II central truss assembly would apparently occur in open space.
Following truss assembly, spacewalking astronauts would install a wide variety of systems inside and outside the truss. These would include 20 rectangular 25-meter-long radiators for cooling
Discovery II's electricity-generation systems. Each radiator would reach orbit folded like an accordion.
The HLLV's 250-metric-ton weight limit dictated that the 310-metric-ton reactor reach space in two launches. The NASA Glenn engineers proposed launching part of the fusion reactor — its poloidal magnetic coils — with the truss payload. This meant that, in addition to the truss and attached components, spacewalking astronauts would need to piece together
Discovery II's most complex and important hardware element.
The second HLLV payload would include the remainder of the fusion reactor and the magnetic rocket nozzle. The third — the 172-metric-ton "artificial gravity crew payload" — would comprise seven pressurized crew modules. The NASA Glenn team offered no insight into how to how the crew modules would join together automatically in assembly orbit. The fourth through seventh payloads would each comprise a filled slush hydrogen propellant "cryo-tank." Thrusters and avionics would permit each to maneuver gingerly into place near
Discovery II's tail.
 |
| Discovery II with selected components and dimensions indicated. Please click on image to enlarge. Image credit: NASA. |
The NASA Glenn team had
Discovery II saving reactor fuel and propellant by departing the Earth-Moon system from a loose, distant, "sub-parabolic" orbit, but gave no indication as to how she would reach her departure orbit from her assembly orbit. Presumably the spacecraft would be moved using space tugs.
An air-breathing space plane would deliver a six-to-12-person crew to a space station in low-Earth orbit. There they would board a taxi vehicle for the journey to the waiting
Discovery II. They would dock with its
only docking port, located on the front of the central hub crew module, and transfer to their interplanetary spacecraft.
Crews returning from Saturn would park the spacecraft in sub-parabolic orbit and await retrieval.
Discovery II would be designed for reuse, though how she would be refueled, resupplied, and refurbished in sub-parabolic orbit after each flight was left to the reader's imagination.
Preparation for departure would require weeks. The magnets and reactor structure would need to be thoroughly cooled using liquid helium; the chief reason for the long preparation period, however, would be the need to charge a five-metric-ton nickel-hydrogen battery bank. A two-megawatt, 10-metric-ton auxiliary fission reactor inside the central truss would slowly charge the batteries in preparation for the roughly one-gigawatt burst of radio-frequency energy needed to start fusion in the reactor. The NASA Glenn team called this start-up technique "high harmonic fast wave heating."
D/He-3 fuel would enter the reactor rather spectacularly in the form of one-gram, 2.2-centimeter cube-shaped "pellets" accelerated at 27,580 gravities inside a 185-meter-long electromagnetic rail-gun. How the long, complicated rail-gun would be assembled in space within the central truss was not described.
The solid-deuterium/liquid-helium-3 pellets would enter the reactor moving at 10 kilometers per second, so would deeply penetrate the dense plasma torus. This would, the NASA Glenn engineers explained, help to preserve the stability of the swirling plasma flow. Pellets would need to be injected into the reactor once per second to maintain steady energy output. Swirling plasma in the fusion reactor torus would at start-up torque (twist) the central truss.
Discovery II's maximum acceleration would reach 1.9 milligravities as she closed in on her target planet, when her cryo-tanks would be nearly empty. This acceleration, though minute, would also place strain on the central truss, as would operation of various turbines and movement of coolant and working fluids through pipes and pumps. The D/He-3 fuel injector would generate a four-gravity load each time it fired a pellet. The NASA Glenn team suggested that a flywheel might absorb some of the forces
Discovery II would experience, but provided little information as to how this would function.
The revolving crew section would also place strain on the truss. Though they noted that data concerning a healthful level of artificial gravity do not yet exist, NASA Glenn team opted to provide
Discovery II's astronauts with artificial gravity one-fifth as strong as Earth surface gravity. Three arms 17 meters long would each connect a 5.6-meter-tall, 7.5-meter-diameter lab/hab module to a 7.5-meter-diameter central hub where weightless conditions would prevail. The artificial-gravity system would spin 3.25 times per minute.
The three two-deck lab/hab modules would contain accommodations for four astronauts each. Opting for separate lab/hab modules connected only through a hub would mean that the "hamster wheel" jogging routine demonstrated in the film
2001 could not take place.
All crew modules would include a layer of water between two layers of graphite epoxy hull material for radiation protection. The water would also serve as a heat dump for crew module thermal control. To augment the water shielding, the central hub would contain a solar-flare storm shelter with additional shielding.
Discovery II would arrive in Saturn sub-parabolic orbit with nearly empty cryogen tanks. Her crew would carefully shut down her fusion reactor and begin charging her battery bank for another start-up in several weeks' time.
The NASA Glenn team offered only a vague vision of how their ship might refuel for the trip home to Earth. Robotic fuel-gathering systems, perhaps suspended from balloons, might be placed into Saturn's atmosphere. They would need to process hundreds of kilograms of gas to obtain a single gram of helium-3 or deuterium and tens of thousands of tons to collect the 11 metric tons required to refuel
Discovery II for the trip back to Earth.
No indication was given as to how D/He-3 mining machinery would reach Saturn's atmosphere ahead of
Discovery II. Nor did the NASA Glenn team explain how D/He-3 mined from Saturn's atmosphere would reach the automated Saturn-orbiting refueling station they assumed would be in place when
Discovery II arrived.
NASA Glenn envisioned that
Discovery II's empty self-propelled hydrogen tanks would separate and dock autonomously with the refueling station. Identical full tanks would, meanwhile, undock from the station, rendezvous with
Discovery II, and take the place of the depleted ones. How the hydrogen would reach the station was left to the imagination.
Discovery II would carry no auxiliary craft, so would need vehicles pre-deployed at Saturn if her crew was to leave the ship and land on any of the ringed planet's many moons. The NASA Glenn team did not explain how such auxiliary craft might reach Saturn ahead of
Discovery II, nor how they would be maintained after they became based in Saturn's neighborhood.
Could NASA Glenn's
Discovery II replicate the capabilities of
Discovery in the book and film
2001: A Space Odyssey? As detailed in the second part of this three-part post series, the film
Discovery differed from the
Discovery of Clarke's novel. The cinematic and literary spacecraft had different propulsion systems, though both relied on nuclear fission.
Discovery of the film was a gas-core nuclear-thermal rocket;
Discovery of the book employed electromagnetic "plasma jets" that drew electricity from a fission reactor.
Both of
2001's
Discovery spacecraft — admittedly fictional, but designed with great concern for realism — could travel round-trip to Jupiter without reliance on pre-deployed assets. Both were adaptable enough that they could be diverted from Jupiter to Saturn when the need arose. That adaptability was based on advanced crew support (hibernation) and automation (HAL 9000) systems. Those advanced non-propulsion systems meant that a round-trip Jupiter mission could be re-planned as a one-way Saturn mission with eventual crew retrieval by a separately launched spacecraft.
Though it promises an impressive fusion rocket capability, the NASA Glenn
Discovery II design is incomplete. It fails to account for the existence at Saturn of extensive pre-deployed assets essential to
Discovery II's mission. Furthermore, it emphasizes propulsion to the exclusion of other potentially groundbreaking, mission-shaping technologies. For these reasons, NASA Glenn's
Discovery II cannot be said to replicate the capabilities of the
Discovery spacecraft portrayed in the book and film
2001: A Space Odyssey.
 |
| Saturn viewed by the Cassini spacecraft from an orbital position north of the planet's equator. The gray north polar region and peculiar spinning hexagonal polar vortex at its center are just visible. Image credit: NASA. |
Sources (please also see Part 1 and Part 2 Sources)
Realizing "2001: A Space Odyssey": Piloted Spherical Torus Nuclear Fusion Propulsion, NASA/TM-2005-213559, C. Williams, L. Dudzinski, S. Borowski, and A. Juhasz, NASA Glenn Research Center, March 2005.
2001: A Space Odyssey, Arthur C. Clarke, New York: New American Library, October 1999, pp. 80-82, 85-101, 120-203.
